FrameMaker Ver.5.5E(PC) Di152/Di183 TROUBLESHOOTING
01.09.04
T-50
Section Step Check Result Action
Input
system
5 Exposure Lamp is abnormally lit (flickers
or abnormally dark) when the Start key
is pressed.
NO • Go to step 7.
6 Inverter Board (copier: PU2) connector
CN1PU2 is loose.
YES • Reconnect.
NO • Change Exposure
Lamp (LA2).
7 CCD Board (copier: PWB-J) connector
PJ7C is loose.
YES • Reconnect.
NO • Change Inverter Board
(PU2).
• Change Control Board
(copier: PWB-C).
