FrameMaker Ver5.5E(PC) Di152/Di183 MECHANICAL/ELECTRICAL
01.09.05
M-31
Paper Size Detecting Board
PWB-I
Paper Size Detecting
Sensor S11
Paper Size
SW1 SW2 SW3 SW4
———— — B4L, 8-1/2 × 14
———— Activated 11 × 14
———ON Activated A3L, 11 × 17
——ON ON — A5L, 5-1/2 × 8-1/2 L
——ON ON Activated A4C, 8-1/2 × 11 C
— ON —— — A5C, 5-1/2 × 8-1/2 C
— ON ON ON — A5L, 5-1/2 × 8-1/2 L
— ON ON ON Activated A4C, 8-1/2 × 11 C
ON ——— — FLS
ON ON —— — FLS
ON ON ON ON — A4L, 8-1/2 × 11 L
Elevtrical Component Control Signal ON OFF Wiring Diagram
PWB-I SW1 PWB-A PJ15A-1 L H
2-H
PWB-I SW2 PWB-A PJ15A-2 L H
PWB-I SW3 PWB-A PJ15A-3 L H
PWB-I SW4 PWB-A PJ15A-4 L H
Elevtrical Component Control Signal Activated Deactivated Wiring Diagram
S11 PWB-A PJ15A-7 H L 1-H
To Next Page
