FrameMaker Ver.5.5E(PC) DIS/REASSEMBLY, ADJUSTMENT FOR Di152/Di183
01.09.03
D-8
No. Part Name Removal Procedure
1 Original Cover Pull the Original Cover straight up.
2 Original Glass
Remove no. 18.
→ Remove two holding brackets or no. 11 and
the Original Glass.
3 Control Panel
Remove two control panel mounting screws.
→ Remove two
ground wire mounting screws. → Remove one flat cable and
unplug one connector.
4 Right Inside Cover
Remove no. 5.
→ Remove one Right Inside Cover mounting
screw.
5Front Cover
Remove no. 3.
→ Open the Front Door and remove six Front
Cover mounting screws.
6Front Door
Open the Front Door and remove one band mounting screw.
→
Snap off one C-clip.
71st Tray
Slide out the 1st Tray.
→ Remove the fixing brackets on the right
and left.
8 Left Cover
Remove no. 3.
→ Remove no. 5. → Remove no. 14. → Remove
five Left Cover mounting screws.
9 Upper Cover
Remove no. 3.
→ Remove no. 5. → Remove no. 14. → Remove
no. 8.
→ Remove two screws and two Upper Cover mounting
screws.
10 Rear Inside Cover
Remove no. 3.
→ Remove no. 5. → Remove no. 14. → Remove
no. 8.
→ Remove no. 9. → Remove no. 4. → Remove two Rear
Inside Cover mounting screws.
11 ADF Glass Remove two ADF Glass mounting screws.
12 Left Hinge Remove no. 14.
→ Remove three Left Hinge mounting screws.
13 Right Hinge Remove no. 14.
→ Remove three Right Hinge mounting screws.
14 Rear Cover Remove six Rear Cover mounting screws.
15 Rear Right Cover
Remove no. 14.
→ Remove one Rear Right Cover mounting
screw.
16
Multiple Bypass
Cover (when the
option is mounted)
Remove two Multiple Bypass Cover mounting screws.
17 Right Door
Remove no. 14.
→ Remove no. 15. → Remove three Right Door
mounting screws.
18 Right Cover
Remove no. 3.
→ Remove no. 5. → Remove no. 14. → Remove
four Right Cover mounting screws.
To Next Page
