Digi Connect IT 4 User Manual

Serial port Configure Modbus mode
Digi Connect IT® 4 User Guide
249
d. Specify the data type:
(config)>serial port1 logging type value
(config)>
where value is one of:
n received
n transmitted
n both
n arrows. This is the default.
e. Log the time at which date was received or transmitted:
(config)>serial port1 logging hex true
(config)>
f. Log data as hexadecimal values:
(config)>serial port1 logging timestamp true
(config)>
17. Save the configuration and apply the change:
(config)> save
Configuration saved.
>
18. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
Configure Modbus mode
Modbus mode allows you to use the serial port for Modbus. See Modbus gateway.
To change the configuration to match the serial configuration of the device to which you want to
connect:
Web
1. Log into the Connect IT 4 WebUI as a user with Admin access.
2. On the menu, click System. Under Configuration, click Serial Configuration.
The Serial Configuration page is displayed.
