User authentication LDAP
Digi Connect IT® 4 User Guide
691
(config)> auth radius nas_id id
(config)>
6. Add a RADIUS server:
a. Add the server:
(config)> add auth radius server end
(config auth radius server 0)>
b. Enter the RADIUS server's IP address or hostname:
(config auth radius server 0)> hostname hostname|ip-address
(config auth radius server 0)>
c. (Optional) Change the default port setting to the appropriate port:
(config auth radius server 0)> port port
(config auth radius server 0)>
d. Configure the amount of time in seconds to wait for the RADIUS server to respond. Allowed
value is any integer from 3 to 60. The default value is 3.
(config auth radius server 0)> timeout value
(config auth radius server 0)>
e. (Optional) Repeat the above steps to add additional RADIUS servers.
7. Add RADIUS to the authentication methods. Authentication methods are attempted in the
order they are listed until the first successful authentication result is returned. This example
will add RADIUS to the end of the list. See User authentication methods for information about
adding methods to the beginning or middle of the list.
(config)> add auth method end radius
(config)>
8. Save the configuration and apply the change:
(config)> save
Configuration saved.
>
9. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
LDAP
Your Connect IT 4 device supports LDAP (Lightweight Directory Access Protocol), a protocol used for
directory information services over an IP network. LDAP can be used with your Connect IT 4 device for
centralized authentication and authorization management for users who connect to the device. With
LDAP support, the Connect IT 4 device acts as an LDAP client, which sends user credentials and
connection parameters to an LDAP server. The LDAP server then authenticates the LDAP client
requests and sends back a response message to the device.
