Digi Connect IT 4 User Manual

Virtual Private Networks (VPN) L2TP
Digi Connect IT® 4 User Guide
451
Show the status of L2TP access connectors from the WebUI
1. Log into the Connect IT 4 WebUI as a user with Admin access.
2. On the menu, select Status. Under VPN, select L2TP > Access Connectors.
The L2TP Access Connectors page appears.
3. To view configuration details about an L2TP access connector, click the  (configuration) icon
in the upper right of the tunnel's status pane.
Show the status of L2TP network servers from the WebUI
1. Log into the Connect IT 4 WebUI as a user with Admin access.
2. On the menu, select Status. Under VPN, select L2TP > Network Servers.
The L2TP Network Servers page appears.
3. To view configuration details about an L2TP network server, click the  (configuration) icon in
the upper right of the tunnel's status pane.
Command line
Show the status of L2TP access connectors from the Admin CLI
1. Select the device in Remote Manager and click Actions > Open Console, or log into the
Connect IT 4 local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. To display details about all configured L2TP access connectors, type the following at the
prompt:
> show l2tp lac
Name Enabled Status Device
--------- ------- ------ -----------
lac_test1 true up test_device0
lac_test2 true pending
>
3. To display details about a specific tunnel:
> show l2tp lac name lac_test2
lac_test2 L2TP Access Concentrator Status
------------------------------------
Enabled : true
Status : pending
>
4. Type exit to exit the Admin CLI.
Depending on your device configuration, you may be presented with an Access selection
menu. Type quit to disconnect from the device.
