Dynojet 200iX User Manual

CHAPTER 3
Extended Carriage
Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
3-20
7 Secure the trike carriage adapter assembly to the dyno and the extended support
using five 5/16 x 1-inch button-head bolts as shown in Figure 3-21.
8 Secure the trike carriage adapter assembly to the dyno and the extended support
using two 3/8 x 1-inch button-head bolts as shown in Figure 3-21.
9 Lube the tracks with the included lube or use grease.
Figure 3-21: Installing the Trike Carriage Adapter Assembly
KU074
5/16 x 1-inch bolts
3/8 x 1-inch bolts
trike carriage
adapter assembly
extension support
5/16 x 1-inch bolts
