Eaton easy500, easy700

4 Wiring  with
4.15 Circuit examples
Operating instructions 05/10 MN05013003Z-EN www.eaton.com 161
Figure 89: Stairwell lighting with easy
Button pressed briefly
Light ON or OFF. The impulse relay function will even switch off Continuous lighting.
Light off after 6 min. with Continuous lighting this function is not active.
Button pressed for more
than 5 s
continuous light
N
L
S1
S2
S3
E1
E2
E3
1
2
Q1
I1
L
N
