ECKELMANN UA 400 - Terminal Assignment of the 230 V AC Relay Outputs

Firmware V3.15
21.04.2021
109/401
7.3 Terminal assignment of the 230 V AC relay outputs

Warning - hazardous electrical voltage!
Danger of electric shock! BEFORE andAFTERconnectionitmustcheckedthatthe230VACrelay
outputsareoff load!Lowvoltageandsafetyextra-lowvoltagemustnotbeappliedtogetheratthe
relay outputs.

