ECKELMANN UA 400 - Menu 2 Setpoints UA 141

Firmware V3.15
21.04.2021
297/401
•
•
9.6.3 Menu 2 Setpoints UA 141
SETPOINTS POS: XXXXX
1 Cooling Menu 2-1; Special case: Move to menu 2-1-1 when single-zone operation is set
(Menu 6-1) and setpoint toggle is disabled (Menu 3-3).
2 Defrost Menu 2-2; Special case: Move to menu 2-2-1 when single-zone operation is set
(Menu 6-1) and setpoint toggle is disabled (Menu 3-3).
3 Not used with this controller type
4 Alarm Menu 2-4; Special case: Move to menu 2-4-1 when single-zone operation is set
(Menu 6-1) and setpoint toggle is disabled (Menu 3-3).
5 Not used with this controller type
6 Pane Heater Move to menu 2-6
Menu2-1Cooling
COOLING POS: XXXXX
1 Zone 1 Menu 2-1-1
2 Zone 2 Menu 2-1-2
Only shown when two-zone operation is set (Menu 6-1)
3 Zone 1A Altern. Menu 2-1-3
Not shown when setpoint toggle is disabled (Menu 3-3)
4 Zone 2A Altern. Menu 2-1-4
Only shown when two-zone operation is set (Menu 6-1) and setpoint toggle is not
disabled (Menu 3-3)
Menu2-1-1Zone1
COOLING 1 POS: XXXXX Entry Default
Setpoint R2.1 XXX °C Supply air temperature setpoint -20..20 -4 °C
Hystersis R2.1 X K Supply air temperature hysteresis setpoint 1..8 4 K
Setpoint R4.1 XXX °C Return air temperature setpoint for comparison -15..20 2 °C
Hystersis R4.1 X K Return air temperature hysteresis setpoint 1..8 2 K
Humid. On Time 0m Humidifier on time
Only shown when single-zone operation is set
(Menu 6-1)
--, 0..15 5 m
