ECKELMANN UA 400 - Setpoint Toggle (Day; Night Operation)

Firmware V3.15
21.04.2021
68/401
•
•
•
5.13 Setpoint toggle (day / night operation)
Controller setpoints can be entered double as a standard value and an alternative value. Setpoint toggle allows
changingbetweenthesetwovalues.Setpointtogglingcanbemadeintwoways:
External: By voltage applied to 230 V- Digital Input 2 (Terminal D21/D22, factory setting) by a switch or
timer. Alternatively, with an appropriate parameterization of the digital inputs (menu 6-2-4), the setpoint
switch can be carried out via digital input 1 (terminals D11/D12) or digital input 4 (terminals D41/D42). The
functionofthedigitalinputscanbeconfiguredviatheparametersInv.D1 to Inv.D4(menu6-2-4).Ifmore
than one input has been parameterized with the same function, then this function is active as soon as a
signal is applied to one of these inputs.
Internal:Bysettingtoggletimesontheinternalclock.(onlyactivewhentheparameterToggle interv.(Menu
3-3) is set to "--").
CAN bus: With the use of a system centre or a suitable store computer (version 4.24 or higher) he setpoint
can also be controlled from the system centre / store computer via CAN bus. Further information on setpoint
switching can be found in the system centre's / store computer's documentation in the chapter "Special
Inputs".
UA 111, UA 111 D, UA 121:
The fan stops for an adjustable time (night blind close time). The fan restarts when toggling back from
alternative to standard setpoints.
Night blind run time
UA 141, UR 141 TK (LT), UR 141 NK (NT)
Warning - hazardous electrical voltage!
Danger of electric shock! BEFOREconnectinganddisconnectingitmustbecheckedthatthe230
VACdigitalinputsareoff load! The controller and connected voltage carrying components remain
supplied with power!

Night blind close timeAsarule,thenightblindisclosedonrefrigeratedmultideckswhentoggling
setpoints. Some cases require the fans to be stopped while the night blind is being closed to prevent it
from being forced out of the case.

Setpoint toggle can be activated via digital Input 2 (terminals D21 and D22). This requires digital Input
2 to be set as SETP.TOGGLE (Menu 6-2-4) for external setpoint toggle to be available.

