ECKELMANN UA 400 - Naming of the Controller

Firmware V3.15
21.04.2021
92/401
•
•
10. Tap the ESC button twice to exit the menu 3 Toggle Setpoint.
11.Selectmenu2 Setpoints - 1 Cooling - Zone 1 / Zone 2 / Zone 1U / Zone 2U.
2 Setpoints - 1 Cooling - Zone 1 - 2 - Um1 - Um2
KÜHLUNG xPOS: XXX
...
Überhitzung XK Superheat setpoint of the superheat controller
Min. Überh. XK If the minimum superheat is undercut, the controller closes the associated E-
valve and sets the I-sum (NOT: I-component) to 0 if the parameter Reset I-
Summ is set to ON.
Zweipunktreg .AUS The temperature control no longer operates continuously but as on-off
controller. This is used for enable / disable of the superheat control (TEV
emulation).
MOP-Punkt XX°C Avaluenotequalto"–"mustbesethereiftheMOPfunctionisrequired.Ift0
exceeds this value, the opening degree is reduced as t0 rises.
12. Return to the main menu of the store computer / operator terminal by tapping the ESC button multiple
times.
13. Select the menu 7 Monitoring - 3 Configuration in the main menu of the store computer / operator
terminal and input, among other things, the node name of the case controller in plain text.
7 Monitoring - 3 Configuration
KONFIGURATION Kn.nnn Input of the CAN bus address: Select the case controller with the corresponding
CAN bus address (node No. = 1..99) to be parametrised using the cursor or by
direct input.
Teilnehmername Input node name (e.g. Cheese Counter)
Position XXXXX Input of the position of the node in the store
Priorität X Input of the desired priority
14. Ending basic configuration of the controller Tap the ESC button multiple times to return to the main
menu. This ends the basic configuration.
6.4.1 Naming of the controller
The following parameters are available for naming the controller:
Refrigeration point name (19 characters, can be freely edited)
Refrigeration point position (5 characters, can be freely edited)
The controller can be named using the system centre, store computer, operator terminal or the PC software
LDSWin.
A. BT 300 operator interfacetheinputismadeinMenu6-1.
B. System centreSeechapterSystem Centre for details.
A. Store computer / operator terminaltheinputismadeinMenu7-2.
D. PC software LDSWinSeeoperatingmanualofLDSWin.
Any naming of the controller with a BT 300 x operator interface is only possible for the UA 410 L
controller.

