ECKELMANN UA 400 - Menu 2 Setpoints UA 111

Firmware V3.15
21.04.2021
147/401
•
•
•
•
9.1.3 Menu 2 Setpoints UA 111
SETPOINTS POS: XXXXX
1 Cooling Move to menu 2-1 Special case: Move to menu 2-1-1 when single-zone operation is
set (Menu 6-1) and setpoint toggle is disabled (Menu 3-3).
2 Defrost Move to menu 2-2 Special case: Move to menu 2-2-1 when single-zone operation is
set (Menu 6-1) and setpoint toggle is disabled (Menu 3-3).
3 Not used with this controller type
4 Alarm Move to menu 2-4 Special case: Move to menu 2-4-1 when single-zone operation is
set (Menu 6-1) and setpoint toggle is disabled (Menu 3-3).
5 Frame Heater Move to menu 2-5
Menu2-1Cooling
COOLING POS: XXXXX
1 Zone 1 Menu 2-1-1
2 Zone 2 Menu 2-1-2
Only shown when two-zone operation is set (Menu 6-1)
3 Zone 1A Altern. Menu 2-1-3
Not shown when setpoint toggle is disabled (Menu 3-3)
4 Zone 2A Altern. Menu 2-1-4
Only shown when two-zone operation is set (Menu 6-1) and setpoint toggle is not
disabled (Menu 3-3)
Menu2-1-1Zone1
COOLING 1 POS: XXXXX Entry Default
Setpoint R2.1 XXX °C Supply air temperature setpoint -10..20 -2 °C
Hystersis R2.1 X K Supply air temperature hysteresis setpoint 1..8 4 K
Setpoint R4.1 XXX °C Return air temperature setpoint for comparison -10..25 5 °C
Hystersis R4.1 X K Return air temperature hysteresis setpoint 1..8 2 K
Menu2-1-2Zone2
COOLING 2 POS: XXXXX Entry Default
Setpoint R2.3 XXX °C Supply air temperature setpoint -10..20 -2 °C
Hystersis R2.3 X K Supply air temperature hysteresis setpoint 1..8 4 K
Setpoint R4.3 XXX °C Return air temperature setpoint for comparison -10..25 5 °C
Hystersis R4.3 X K Return air temperature hysteresis setpoint 1..8 2 K
Menu2-1-3Zone1AAltern.
