5 Function of UA 400 / UA 410
5.1 Starting characteristics
The following are distinguished for any start-up of the controller:
First start
Restart
5.1.1 First start- reset controller to factory settings
The first start can be initiated using the following procedure:
Disconnect controller from the power supply for safety reasons (see also chapter Setting of the controller
type and master/slave mode) make a note of the DIP switch S3 settings (e.g. OFF-ON-OFF-...).
Adjust settings at the DIP switch S3 (e.g. OFF-OFF-OFF-...).
Power on the controller again and wait approx. 1 minute while the controller starts up.
Disconnect controller from the power supply for safety reasons (see also chapter Setting of the controller
type and master/slave mode).
Reset DIP switch S3 to the noted starting position.
Switch on controller again.
The settings of the controller have been reset to the factory settings.
5.1.2 Restart - restart of the controller
For a restart, the device is restarted with all configured parameters and the CAN bus address set on the rotary
switch. A restart can be initiated using the following procedure:
Disconnection and reconnection of the power supply
The parameters mentioned in this section are described in Menu structure UA 400. Changing the
default settings for these parameters will not normally be necessary. Parameters that cannot be
changed are referred to as fixed parameters in the following description.
Caution: data loss!Afirststartcausesallparameterstoberesettothefactorysettings!
Afirststartisalsoperformedwhenadifferentcontrollerversion(e.g.UA400UA410DUA400EUA
410 L) is loaded on the controller via firmware update (see chapter Battery replacement). A sensor
scan (Menu 6-1) must be performed during commissioning or after a first start! The sensor scan is the
only possibility to define the sensors to be monitored; see chapter Necessary and optional sensors.
