8 Operation of UA 400
8.1 Operation possibilities
The controller provides menus and screens for the display and adjustment of values. However, no operation
forthisisprovidedonthecontrolleritself.Theactualoperationofthesemenusisperformedexternallyusing
thefollowingpossibilities:
Local operation with a BT 300 x operator interface:Theoperationisperformeddirectlyon-siteatthe
controllerwithanoperatorinterfaceoftheBT300series.
SeechapterLocal operation with a BT 300 x operator interfacefordetailsfortheoperation.

Remote control via the terminal:Thecontrollercanbeoperatedremotely(e.g.fromthemachineroom)
usingthesystemcentre,astorecomputeroranoperatorterminal.Thecommunicationwiththecontrolleris
performedviatheCANbus

SeechapterRemote control via a terminalfordetailsfortheoperation.
Remote control with PC software LDSWin:APCwithLDSWininstalledisconnectedtothesystem
centreorthestorecomputer.Theconnectioncanbemadehere,forexample,viatheserialinterface,a
modem,anetworkorthePC-CANbusadapter.Inthisway,thecontrollercanbeoperatedveryconveniently
withthePCsoftwareanditspowerfulfunctionssuchascontrolleranalysis,evaluations,storingparameter
sets,creatinglists,etc.
See the LDSWin operating instruction for details about the range of functions.
