8.3.3 Deactivating the input lock-down
Operation via system centre, store computer or operator terminal is only possible for controllers with CAN
busconnection;theremovalofthelock-downisthenapplicableforallcomponentsintheCANbussystem.
Thelock-downisautomaticallyreactivated15minutesafterthelastbuttontap.
Before entering values, the input lock-down must be removed as follows:
8.3.3.1 Store computer CI 3x00 / operator terminal AL 300
Before entering values, the input lock must be removed from the store computer or operator terminal as follows:
Step 1:Selectmenuitem9"Parametrisation"inthemainmenu.
Step 2:Selectmenuitem3"Lock-down"inthismenu.
Step 3:
A. Unlocking store computer (standard)TaptheENTERbutton(↵)tosetthemarker(√).Thelock-down
hasnowbeendeactivatedanditispossibletomakesettings.
or
B. Unlocking store computer and activating Superuser mode (Superuser permissions)Inputcurrent
datebackwards(nothingisshownonthedisplay).Example:ThecurrentdateisApril17,2016,i.e.
17/04/16;therequiredinputforenablingSuperuserpermissionsisthen614071.
ConfirmtheinputwiththeENTERbutton(↵);an"S"isshownonthedisplay.
Step 4:ExittheoperatingscreenandreturntothemainmenubytappingtheESCbuttontwice.
8.3.3.2 System centre CI 4x00
Login to and logout (unlock and lock-down) of the system centre:
The release of the lock-down must only be carried out by service personnel.

Tip: If you are already in the user interface of a CAN bus node but have forgotten to release the input
lock-down, you can unlock the input lock-down for this controller using the button combination MODE
and the input lock-down is active again as soon as you exit the user interface of the controller.

