12 Specifications of UA 400
12.1 Electrical data
UA 400 CC / UA 400 AC
Electrical data
Operating voltage 230 V AC (+/- 10%), 50/60 Hz (+/- 3 Hz)
Rated power 11 VA
Leakage current via PE max 1 mA
Rated surge voltage 2.5 kV for overvoltage category II
4.0 kV for overvoltage category III
Relay outputs 4 x normally open contact, 250 V AC, floating output, min 10 mA
Load type: ohmic: max. 6 A, inductive: max. 3 A, cos phi = 0.4
3 x changeover contact, 250 V AC, floating output, min 10 mA
Load type: ohmic: max. 6 A, inductive: max. 3 A, cos phi = 0.4
Transistor outputs 2 x 24 V DC pull down switching transistor with internal current limitation to 50
mA for lighting control and frame heater
Digital inputs 4 x 230 V AC, floating output
Real-time clock Only UA 400 AC:
With power reserve and lithium cell (for details, see ""Transport and storage")
Accuracy: typical 12 minutes per year at 25 °C
Field bus interface CAN bus, floating output
Data ports DISPLAY: BT 300 x operator interface and up to four BT 30CI320 (TTY)
temperature displays: Communication with the PC software for reading out the
operating data
USB port For firmware update (in future it will be possible to connect a notebook (PC) to
this interface for the direct parameterisation via LDSWin)
Monitoring function Watchdog
Environmental conditions
Warning about dangerous electrical voltage! Danger to life - Danger of electric shock!
Overvoltage category III (test voltage 4.0 kV) / contamination degree 2:Allconnectionsofthe
device provided for operation with 230 V AC supply voltage must be wired with the same phase
conductor. 400 V AC between neighbouring connection terminals is notpermitted!
Overvoltage category II (test voltage 2.5 kV) / contamination degree 2 or
overvoltage category II (test voltage 2.5 kV) / contamination degree 1:Differentphaseconductors
may be used. 400 V AC between neighbouring connection terminals is permitted!
