ECKELMANN UA 400 - Controller Type UA 111 D - Menu Tree

Firmware V3.15
21.04.2021
170/401
9.2 Controller type UA 111 D - menu tree
DIP switch S3 UA 111 D
1: OFF
2: ON
3: ON
4: ON/OFF = Master / Slave mode ON/OFF
5..8: OFF
9: ON
Main menu Submenu Submenu 2 Menu number Menu name
0 REFRIGERATION POINT
Actual values 1 ACTUAL VALUES
Temperature sensor 1-1 TEMPERATURE
Cooling Zone 1 1-2 COOLING 1
Defrost Zone 1 1-3 DEFROST 1
–
Alarm 1-5 ALARM
Frame heater 1-6 FRAME HEATER
Setpoints 2 SETPOINTS
Cooling 2-1 COOLING
Zone 1 2-1-1 COOLING 1
–
Zone 1 U Toggle 2-1-3 COOLING 1U
Defrost 2-2 DEFROST
Zone 1 2-2-1 DEFROST 1
–
Zone 1 U Toggle 2-2-3 DEFROST 1U
–
Alarm 2-4 ALARM
Zone 1 2-4-1 ALARM 1
–
Zone 1 U Toggle 2-4-3 ALARM 1U
