ECKELMANN UA 400 - Page 169

Firmware V3.15
21.04.2021
169/401
• Menu 6-7-2 Service Mode
Service Mod POS: XXXXX Input Default
Relais 1x Relay 1 (terminals 15/16/18)
switch on or switch off (1 or 0)
0 / 1 0
Relais 2x Relay 2 (terminals 25/26/28)
switch on or switch off (1 or 0)
0 / 1 0
Relais 3x Relay 3 (terminals 35/36/38)
switch on or switch off (1 or 0)
0 / 1 0
Relais 4x Relay 4 (terminals 43/44)
switch on or switch off (1 or 0)
0 / 1 0
Relais 5x Relay 5 (terminals 53/54)
switch on or switch off (1 or 0)
0 / 1 0
Relais 6x Relay 6 (terminals 64/65)
switch on or switch off (1 or 0)
0 / 1 0
Relais 7x Relay 7 (terminals 73/74)
switch on or switch off (1 or 0)
0 / 1 0
24V Out 1x Transistor output 1 (terminals 81/82)
switchonorswitchoff(24VDC/50mA)
0 / 1 0
24V Out 2x Transistor output 2 (terminals 91/92)
switchonorswitchoff(24VDC/50mA)
0 / 1 0
ANA OUT 1xxxV Analogue output 1 (terminals 29/30)
defaultvalue0..10VDC
0..10 0.0V
ANA OUT 2xxxV Analogue output 2 (terminals 31/32)
defaultvalue0..10VDC
0..10 0.0V
ANA IN 1xxmA Current at analogue input 1 (terminals 11/12)
4..20 mA
4..20 mA
ANA IN 2xxmA Current at analogue input 2 (terminals 11/14)
4..20 mA
4..20 mA
InputD 1xxx Status digital input 1
ON = Voltage 230 V AC applied
OFF = No voltage
ON/OFF -
InputD 2xxx Status digital input 2
ON = Voltage 230 V AC applied
OFF = No voltage
ON/OFF -
InputD 3xxx Status digital input 3
ON = Voltage 230 V AC applied
OFF = No voltage
ON/OFF -
InputD 4xxx Status digital input 4
ON = Voltage 230 V AC applied
OFF = No voltage
ON/OFF -
