6.4 Basic configuration of the controller
The lock-down must previously be deactivated on the higher level controller (system centre / store computer or
operator terminal) so that configuration settings can be made on the controller.
1. Cancelling entry block
A.BT300operatorinterface;fordetails,seechapterLock-down of the setpoint change
B. System centre via Login symbol; for details, see chapter System Centre.
C.Storecomputer/operatorterminalmenu8-3;fordetails,seechapterStore computer CI 3x00 / operator
terminal AL 300
2. Opening main menu of the controller
A. The main menu of the controller is shown directly in the operator interface.
B. In the system centre, select the required controller in Menu 4-2 and then tap the Remote Control button to
display the main menu of the controller.
C. In the store computer and operator terminal, a selection list of all CAN bus components is displayed in Menu
5 Remote Control. Select the controller with the corresponding CAN bus address (Kn,nnn = 1..99) to be
parametrised in the selection list using the cursor or direct input and recall by tapping the ENTER button so that
the main menu of the controller is displayed.
3. Basic configuration of the controller - select refrigeration point (Menu 6-1)
In order to define the refrigeration point to be regulated by the case controller, various parameters can be
entered and checked:
6 Configuration - 1 Refrigeration point
KÜHLSTELLEPOS: XXX
Refr. Pt. Name: XXXXXX Check refrigeration point name (can only be freely edited using system
centre)
Position: XXXXX Check refrigeration point Item ID (can only be freely edited using system
centre)
Priority: X Alarm priority 0..99 (observe notes in chapter 10.1 "Alarm signalling")
Verbund Nr.: X Number of the compressor pack that supplies the refrigeration point (1 to 9,
important for multiple compressor packs)
Verbundsatz: XXX Zone of the compressor pack that supplies the refrigeration point (Z1/Z2 only
for VS 3010 BS)
Temperaturzonen X Division of the refrigeration point into 1 or 2 zones
Fühleranzahl XX Number of sensors. The number of connected sensors is scanned after
leaving the parameter with the ENTER button.
The menus shown below only provide the overview; the display can be different for certain controller
types. Details are described in the chapter Menüstruktur UA 400.

