ECKELMANN UA 400 - Page 89

Firmware V3.15
21.04.2021
89/401
4. Exit from the menu 1 Refrigeration point by tapping the ESC button once and select menu 6 Configuration
- 2 Controller.
6 Configuration - 2 Controller
REGLERPOS: XXX
1 Type and version Type, serial number and Master / Slave (ON/OFF)
2 Temperature display Adjustment of the displayed temperature value
3 Alarm delay Input of an alarm delay time
4230Vinputs 230 V inputs
5 Sensor type Selection of the temperature sensor of the type L243, K277 or 5K3A1
5. Select menu 6 Configuration - 2 Controller - 3 Alarm delay.
6 Configuration – 2 Controller – 3 Alarm delay.
ALARMVERZ.POS: XXX
Fühlerbruch XXm Alarm delay for sensor fault
Über/Unter Tmp XXXm Alarm delay for high temperature or low temperature
keine Abtauung XXXh Alarm is tripped if no defrost is performed within this configurable time.
SelbsthaltungN NO: Automatic reset of non-transient alarms
YES: Alarms must be reset manually
Exit the menu by tapping the ESC button once.
Risk of failure of alarm messaging in the event of problems!Alarmscanbesuppressedifthe
alarmpriorityissetto0.Thevalueofthesuctionpressureforthecontrolfunctionsisnotavailableto
the case controller until after the pack number of the associated pack controller has been selected on
the case controller.
Risk of damage to the system and stock loss!Itmustbestrictlyensuredthatthecorrectpack
number is set, otherwise this can result in damage to the installation or stock. The setting can be
checkedatRefrigerationpoint-1Actualvalues-1Temperaturesensors.Thevaluet
0
VS korr.
displayed there is the offset corrected t actual value of the pack controller as indicated in the pack
number field. In standalone operation via the local pressure transmitter, the pack number and the
parameter t
0
VS korr. only have any meaning if the signal from the pressure transmitter is not
available. In this case, the controller attempts to replace the missing signal with a pressure value
measured at the pack controller and transmitted via the CAN bus (if available).

A sensor scan (Menu 6-1) must be performed during commissioning or after a first start! The sensor
scan is the only possibility to define the sensors to be monitored; see chapter Notwendige und
optionale Fühler.

