9.4.3 Menu 2 Setpoints UA 131 / UA 131 LS
SETPOINTS POS: XXXXX
1 Cooling Menu 2-1; Special case: Move to menu 2-1-1 when single-zone operation is set
(Menu 6-1) and setpoint toggle is disabled (Menu 3-3).
2 Defrost Menu 2-2; Special case: Move to menu 2-2-1 when single-zone operation is set
(Menu 6-1) and setpoint toggle is disabled (Menu 3-3).
3 Not used with this controller type
4 Alarm Menu 2-4; Special case: Move to menu 2-4-1 when single-zone operation is set
(Menu 6-1) and setpoint toggle is disabled (Menu 3-3).
5 Frame Heater Move to menu 2-5
6 Fans Move to menu 2-6 (Menu only shown when the case controller is configured to UA
131 with fan control (further details in the chapter UA 400 installation and start-up):
Menu2-1Cooling
COOLING POS: XXXXX
1 Zone 1 Menu 2-1-1
2 Zone 2 Menu 2-1-2
Only shown when two-zone operation is set (Menu 6-1)
3 Zone 1A Altern. Menu 2-1-3
Not shown when setpoint toggle is disabled (Menu 3-3)
4 Zone 2A Altern. Menu 2-1-4
Only shown when two-zone operation is set (Menu 6-1) and setpoint toggle is not
disabled (Menu 3-3)
Menu2-1-1Zone1
COOLING 1 POS: XXXXX Entry Default
Setpoint R2.1 XXX °C Supply air temperature setpoint -40..20 -32 °C
Hystersis R2.1 X K Supply air temperature hysteresis setpoint 1..8 2 K
Setpoint R4.1 XXX °C Return air temperature setpoint for comparison -30..20 -20 °C
Hystersis R4.1 X K Return air temperature hysteresis setpoint 1..8 2 K
Menu2-1-2Zone2
COOLING 2 POS: XXXXX Entry Default
Setpoint R2.3 XXX °C Supply air temperature setpoint -40..20 -32 °C
Hystersis R2.3 X K Supply air temperature hysteresis setpoint 1..8 2 K
Setpoint R4.3 XXX °C Return air temperature setpoint for comparison -30..20 -20 °C
Hystersis R4.3 X K Return air temperature hysteresis setpoint 1..8 2 K
