7.12 Assignment of the USB port
The USB port is used
for direct parametrisation of the case controller via LDSWin or
forperformingafirmwareupdateofthecasecontrolleror
for parametrisation of system components via CAN bus using LDSWin (USB2CAN). Furthermore, the
operating data of the case controller can be read out via the USB port using a PC equipped with LDSWin.
IfthecontrollerisconnectedtoaPCviaUSB,thegreenUSBLEDlights.Fordetailsseechapter
Status LEDs A USB A-B cable (see Zubehör) is required for the connection to a PC. Refer to the
LDSWin operating manual for further information about the connection to LDSWin. A detailed
description of the firmware update is contained in chapter Firmware Update.

