ECKELMANN UA 400 - Page 114

Firmware V3.15
21.04.2021
114/401
Controller type D42/D41 D32/D31 D22/D21 D12/D11
Case controller
UA 111, UA 111 D, UA 121,
UA 131 UA 131 LS, UA 131
DD
External alarm
1) 2)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Manual shutdown All
1)
or
Manual shutdown Z1 /
Manual shutdown Z2
Toggle setpoint
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2
Defrost
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
UA 141
External alarm
1) 2)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Pane button
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2
Toggle setpoint
1)
or
Manual shutdown
(All
1)
/ Z1 / Z2) /
Shutdown button
Defrost
1)
or
Manual shutdown
(All
1)
/ Z1 / Z2 /
Toggle setpoint
Cold room controller
UR 141 NK / UR 141 TK
External alarm
1) 2)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Cold room door 1
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2
Cold room door 2
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
Defrost
1)
or
Manual shutdown All /
Manual shutdown Z1 /
Manual shutdown Z2 /
Toggle setpoint
1)
Factory setting
2)
Freelyconfigurablealarmtext-factorysettingis“CO2Alarm”
Ifa230VACvoltageispresentatadigitalinput,theassociatedredLEDlights.Fordetailssee
chapter Status LEDs

