Menu1-5Alarm
ALARM Pos: XXXXX
Alarm Relay XXX Current ON/OFF status of alarm output Terminal 15/16/18
Hi Temp Setp.1 XX °C High temperature setpoint Zone 1
Lo Temp Setp.1 XX K Low temperature setpoint Zone 1
Hi Temp Setp.2 XX °C High temperature setpoint Zone 2;Only shown when two-zone operation is set
(Menu 6-1)
Lo Temp Setp.2 XX K Low temperature setpoint Zone 2;Only shown when two-zone operation is set
(Menu 6-1)
Menu1-6FrameHeater
MODE XXXXX
Frame Heater xxx Current ON/OFF status of frame heater output Terminal 91/92/93
Run Time xxx % Current on time of frame heater
Humidity xxx % Current ambient air humidity (transmitted via CAN bus from pack controller with fitted
ambient humidity sensor)
Room temp xx °C Current ambient air temperature (transmitted via CAN bus from pack controller with
fitted ambient temperature sensor
Menu1-7CoolingZone2
COOLING 2 XXXXX
Cooling XXX Current ON/OFF status of cooling
Run Time XX % Cooling relay on time during last day (00:00 - 24:00 hours)
Starts 0 Cooling relay actuations during last day
Temp. R2.3 XXX °C Current supply air temperature Input Z51/Z52
Setpoint R2.3 XXX °C Supply air temperature setpoint for comparison
Hystersis R2.3 XXX K Supply air temperature hysteresis setpoint
Temp. R4.3 XXX °C Current return air temperature Input Z61/Z62
Setpoint R4.3 XXX °C Return air temperature setpoint for comparison
Hystersis R4.3 XXX K Return air temperature hysteresis setpoint
Menu1-8DefrostZone2
DEFROST 2 Pos: XXXXX
Defrost XXX Current ON/OFF status of defrosting
Temp. R2.3 XXX °C Current supply air temperature Input Z51/Z52
