ECKELMANN UA 400 - Page 175

Firmware V3.15
21.04.2021
175/401
•
•
•
•
Menu1-3DefrostZone1
DEFROST 1 Pos: XXXXX
Defrost XXX Current ON/OFF status of defrosting
Temp. R2.1 XXX °C Current supply air temperature Input Z11/Z12
Temp. R2.2 XXX °C Current supply air temperature Input Z31/Z32
Temp. R2.3 XXX °C Current supply air temperature Input Z51/Z52
Temp. R2.4 XXX °C Current supply air temperature Input Z71/Z72
Temp. R2.5 XXX °C Current supply air temperature Input Z91/Z92
Def. End. Tmp. XXX °C Defrost termination temperature for comparison
Last Defrst XX hh:mm Day and time of last defrost cycle started
M/S Nof. Sl. Number of parameterised and accessible MA slaves
M/S Lost Sl. CAN address of the first MA slave which was not accessible during the last
defrost
M/S Defr.Sl. Number of slaves currently undergoing a defrost
M/S DSlMat List of MA slaves currently undergoing a defrost (can be scrolled through using
ENTER)
DSq Nof. Sl. Number of DS slaves (only in the case of DS master)
DSq Lost Sl. CAN address of the first FA slave which was not accessible during the last defrost
DSq Defr.Sl. Number of slaves currently undergoing defrost
DSq DSlMat List of FA slaves currently undergoing a defrost (can be scrolled through using
ENTER)
Menu 1-4
Not used with this controller type.
Menu1-5Alarm
ALARM Pos: XXXXX
Alarm Relay XXX Current ON/OFF status of alarm output Terminal 15/16/18
Hi Temp Setp.1 XX °C High temperature setpoint Zone 1
Lo Temp Setp.1 XX K Low temperature setpoint Zone 1
Menu1-6FrameHeater
MODE XXXXX
Frame Heater xxx Current ON/OFF status of frame heater output Terminal 91/92/93
Run Time xxx % Current on time of frame heater
