ECKELMANN UA 400 - Page 202

Firmware V3.15
21.04.2021
202/401
•
•
•
•
Menu1-3DefrostZone1
DEFROST 1 Pos: XXXXX
Defrost XXX Current ON/OFF status of defrosting
Temp. R1.1 XXX °C Current supply air temperature Input Z31/Z32
Temp. R1.2 XXX °C Current supply air temperature Input Z51/Z52
Def. End. Tmp. XXX °C Defrost termination temperature for comparison
Wait Time xx m Waiting time setpoint
Drip Time xx m Drain time setpoint
Last Defrst XX hh:mm Day and time of last defrost cycle started
M/S Nof. Sl. Number of parameterised and accessible MA slaves
M/S Lost Sl. CAN address of the first MA slave which was not accessible during the last
defrost
M/S Defr.Sl. Number of slaves currently undergoing a defrost
M/S DSlMat List of MA slaves currently undergoing a defrost (can be scrolled through using
ENTER)
DSq Nof. Sl. Number of DS slaves (only in the case of DS master)
DSq Lost Sl. CAN address of the first FA slave which was not accessible during the last defrost
DSq Defr.Sl. Number of slaves currently undergoing defrost
DSq DSlMat List of FA slaves currently undergoing a defrost (can be scrolled through using
ENTER)
Menu 1-4
Not used with this controller type.
Menu1-5Alarm
ALARM Pos: XXXXX
Alarm Relay XXX Current ON/OFF status of alarm output Terminal 15/16/18
Hi Temp Setp.1 XX °C High temperature setpoint Zone 1
Lo Temp Setp.1 XX K Low temperature setpoint Zone 1
Hi Temp Setp.2 XX °C High temperature setpoint Zone 2;Only shown when two-zone operation is set
(Menu 6-1)
Lo Temp Setp.2 XX K Low temperature setpoint Zone 2;Only shown when two-zone operation is set
(Menu 6-1)
Menu1-6FrameHeater
