ECKELMANN UA 400 - Page 243

Firmware V3.15
21.04.2021
243/401
•
•
•
Menu2-5-2Setpointframeheater
SETPOINTS POS: XXXXX Entry Default
Mod: xxxxxxxxxxxx Displays set frame heater mode (Menu 2-5-1) Fixed on time
Run Time XXX % Fixed on time, Only shown when mode set to
Fixed On Time (Menu 2-5-1)
--, 0..100 100 %
emerg.run time XXX % On time in failure of ambient air humidity or
temperature signal (via CAN bus)
Only shown when mode set to Enthalpy Control
(Menu 2-5-1)
--, 0..100 100 %
enthalp. offs. XXX % Offset to on time with activated enthalpy control
(via CAN bus)
Only shown when mode set to Enthalpy Control
(Menu 2-5-1)
-50..50 0 %
Mod: set point-ctrl Setpoint-dependent control of frame heater
Only shown when mode set to Setpoint-
Dependent On Time (Menu 2-5-1)
- -
Invert Output xxx Inversion of the function of the frame heater
output(terminal 91/92)
, , (ON/OFF)
ON
Menu 2-5-3 Mode altern.
Selectbetweenvalues.Checkmarkshowscurrentsetting.
MODE ALT POS: XXXXX Entry Default
fixed run time Fixed frame heater on time
enthalpy-ctrl rtm Enthalpy control by ambient air temperature and
humidity
set point-ctrl rtm
Setpoint-dependent control of frame heater
Menu2-5-4Setpointaltern.
SOLLW. UM POS: XXXXX Entry Default
Mod: xxxxxxxxxxxx Displays set frame heater mode (Menu 2-5-3 Fixed on time
Run Time XXX % Fixed on time, Only shown when mode set to
Fixed On Time (Menu 2-5-3)
--, 0..100 100 %
emerg.run time XXX % On time in failure of ambient air humidity or
temperature signal (via CAN bus)
Only shown when mode set to Enthalpy Control
(Menu 2-5-3)
--, 0..100 100 %
enthalp. offs. XXX % Offset to on time with activated enthalpy control
(via CAN bus)
Only shown when mode set to Enthalpy Control
(Menu 2-5-3)
-50..50 0 %
Mod: set point-ctrl Setpoint-dependent control of frame heater
Only shown when mode set to Setpoint-
Dependent On Time (Menu 2-5-1)
- -
