• Menu6-7-2ServiceMode
SERVCIE MOD POS: XXXXX Entry Default
Relay 1 x Relay 1 (terminal 15/16/18)
switch on or off (1 or 0)
0 / 1 0
Relay 2 x Relay 2 (terminal 25/26/28)
switch on or off (1 or 0)
0 / 1 0
Relay 3 x Relay 3 (terminal 35/36/38)
switch on or off (1 or 0)
0 / 1 0
Relay 4 x Relay 4 (terminal 43/44)
switch on or off (1 or 0)
0 / 1 0
Relay 5 x Relay 5 (terminal 53/54)
switch on or off (1 or 0)
0 / 1 0
Relay 6 x Relay 6 (terminal 64/65)
switch on or off (1 or 0)
0 / 1 0
Relay 7 x Relay 7 (terminal 73/74)
switch on or off (1 or 0)
0 / 1 0
24V Out 1 x Transistor output 1 (terminal 81/82)
switch on or off (24 VDC / 50 mA)
0 / 1 0
24V Out 2 x Transistor output 2 (terminal 91/92)
switch on or off (24 VDC / 50 mA)
0 / 1 0
ANA OUT 1 xxxV Analog output 1 (terminal 29/30)
Default 0..10 VDC
0..10 0.0V
ANA OUT 2 xxxV Analog output 2 (terminal 31/32)
Default 0..10 VDC
0..10 0.0V
ANA IN 1 xxmA Power analog input 1 (terminal 11/12)
4..20 mA
4..20 mA
ANA IN 2 xxmA Power analog input 2 (terminal 11/14)
4..20 mA
4..20 mA
InputD 1 xxx Status digital input 1
ON = 230 V AC voltage connected
OFF = no voltage present
ON/OFF -
InputD 2 xxx Status digital input 2
ON = 230 V AC voltage connected
OFF = no voltage present
ON/OFF -
InputD 3 xxx Status digital input 3
ON = 230 V AC voltage connected
OFF = no voltage present
ON/OFF -
InputD 4 xxx Status digital input 4
ON = 230 V AC voltage connected
OFF = no voltage present
ON/OFF -
