Menu1-2CoolingZone1
COOLING 1 Pos: XXXXX
Cooling xxx Current ON/OFF status of cooling
Run Time xx % Cooling relay on time during last day (00:00 - 24:00 hours)
Starts 0 Cooling relay actuations during last day
Temp. R2.1 xxx °C Current supply air temperature Input Z11/Z12
Setpoint R2.1 xxx °C Supply air temperature setpoint for comparison
Hystersis R2.1 xxx K Supply air temperature hysteresis setpoint
Temp. R4.1 xxx °C Current return air temperature Input Z21/Z22
Setpoint R4.1 xxx °C Return air temperature setpoint for comparison
Hystersis R4.1 xxx K Return air temperature hysteresis setpoint
Menu1-3DefrostZone1
DEFROST 1 Pos: XXXXX
Defr. Relay 1 Defrost Relay 1
Temp. R1.1 XXX °C Current supply air temperature Input Z31/Z32
Defr. Relay 2 Defrost Relay 2
Temp. R1.2 XXX °C Current supply air temperature Input Z51/Z52
Def. End. Tmp. XXX °C Defrost termination temperature for comparison
Last Defrst XX hh:mm Day and time of last defrost cycle started
M/S Nof. Sl. Number of parameterised and accessible MA slaves
M/S Lost Sl. CAN address of the first MA slave which was not accessible during the last
defrost
M/S Defr.Sl. Number of slaves currently undergoing a defrost
M/S DSlMat List of MA slaves currently undergoing a defrost (can be scrolled through using
ENTER)
DSq Nof. Sl. Number of DS slaves (only in the case of DS master)
DSq Lost Sl. CAN address of the first FA slave which was not accessible during the last defrost
DSq Defr.Sl. Number of slaves currently undergoing defrost
DSq DSlMat List of FA slaves currently undergoing a defrost (can be scrolled through using
ENTER)
Menu1-4Evap.fan
