ECKELMANN UA 400 - Page 276

Firmware V3.15
21.04.2021
276/401
•
•
•
•
Menu3-3ToggleSetpoints
TOGGLE POS: XXXXX Entry Default
Status XXX Setpoint toggle status (OFF/ON) of alternative
set of setpoints (setpoint toggle)
Toggle Setp. XXX Setpoint toggle via
EXT digital input D21/22
INT internal timer
CANbus-„--"deactivated
, ,(EXT,INT,CAN,--)
EXT
Blind On Time x s Fan and cooling stop time after toggling to
alternative set of setpoints with external setpoint
toggle (Menu 3-3)
0..250 0 s
Alt
ON: DD-DD hh:mm
Start time for toggle to alternative set of setpoints
Weekday from - to XXXXX, time hh:mm
Only shown when internal setpoint toggle is
activated (Menu 3-3)
, ,(Mo-Suetc.)or
numbers (hh:mm)
Mo-Su
21:00
Alt
OFF: DD-DD hh:mm
End time for toggle to alternative set of setpoints
Weekday from - to XXXXX, time hh:mm
Only shown when internal setpoint toggle is
activated (Menu 3-3)
, ,(Mo-Suetc.)or
numbers (hh:mm)
Mo-Su
05:00
Alt
ON: DD-DD hh:mm
Start time for toggle to alternative set of setpoints
Weekday from - to XXXXX, time hh:mm
Only shown when internal setpoint toggle is
activated (Menu 3-3)
, ,(Mo-Suetc.)or
numbers (hh:mm)
Su
05:00
Alt
OFF: DD-DD hh:mm
End time for toggle to alternative set of setpoints
Weekday from - to XXXXX, time hh:mm
Only shown when internal setpoint toggle is
activated (Menu 3-3)
, ,(Mo-Suetc.)or
numbers (hh:mm)
Su
21:00
... A total of 7 different ON and OFF toggle times
can be defined. A toggle time will only be obeyed
when a matched pair of on and off times is set as
a parameter.
