ECKELMANN UA 400 - Page 302

Firmware V3.15
21.04.2021
302/401
•
•
•
•
•
•
Menu2-4-3Zone1AAltern.
ALARM 1A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
-10..30 6 °C
Low Temp Setp. XX K Low temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..6 4 K
Menu2-4-4Zone2AAltern.
ALARM 2A POS: XXXXX Entry Default
High Temp Setp XX °C High temperature setpoint at which High
Temperature alarm is generated
-10..30 6 °C
Low Temp Setp. XX K Low temperature setpoint (difference below
temperature control setpoint) at which Low
Temperature alarm is generated
--, 0..6 4 K
Menu 2-5
Not used with this controller type
Menu2-6PaneHeater
PANE HTR POS: XXXXX
1 Mode Pane Move to menu 2-6-1
2 Setpoint Pane Move to menu 2-6-2
Menu 2-6-1 Mode Scheibe
Selectbetweenvalues.Checkmarkshowscurrentsetting.
PANE HTR POS: XXXXX Entry Default
fixed run time
Pane heater fixed on time
enthalpy-ctrl rtm Enthalpy control by ambient air temperature and
humidity
Menu2-6-2SetpointPane
SETPOINTS POS: XXXXX Entry Default
Mod: xxxxxxxxxxxx Set frame heater mode (Menu 2-6-1) Fixed on time
Mod: fixed run time xx m Pane heater on time after actuation of Digital
Input 3 (Terminal D31 and D32)
0..120 60 m
Run Time XXX % Fixed on time,
Only shown when mode set to Fixed On Time
(Menu 2-6-1)
--, 0..100 0 %
emerg.run time XXX % On time in failure of ambient air humidity or
temperature signal (via CAN bus)
Only shown when mode set to Enthalpy Control
(Menu 2-6-1)
--, 0..100 0 %
