ECKELMANN UA 400 - Page 326

Firmware V3.15
21.04.2021
326/401
•
•
•
Menu1-5Alarm
ALARM Pos: XXXXX
Alarm Relay XXX Current ON/OFF status of alarm output Terminal 15/16/18
Hi Temp Setp.1 XX °C High temperature setpoint Zone 1
Lo Temp Setp.1 XX K Low temperature setpoint Zone 1
Hi Temp Setp.2 XX °C High temperature setpoint Zone 2;Only shown when two-zone operation is set
(Menu 6-1)
Lo Temp Setp.2 XX K Low temperature setpoint Zone 2;Only shown when two-zone operation is set
(Menu 6-1)
Cold-room Door1 xxx Cold-room door 1 CLS/OPN
Cold-room Door2 xxx Cold-room door 2 CLS/OPN
Menu1-6FrameHeater
MODE XXXXX
Frame Heater xxx Current ON/OFF status of frame heater output Terminal 91/92/93
Run Time xxx % Current on time of frame heater
Humidity xxx % Current ambient air humidity (transmitted via CAN bus from pack controller with fitted
ambient humidity sensor)
Room temp xx °C Current ambient air temperature (transmitted via CAN bus from pack controller with
fitted ambient temperature sensor
Menu1-7CoolingZone2
COOLING 2 XXXXX
Cooling XXX Current ON/OFF status of cooling
Run Time XX % Cooling relay on time during last day (00:00 - 24:00 hours)
Starts 0 Cooling relay actuations during last day
Temp. R4.3 XXX °C Current room air temperature Input Z71/Z72
Setpoint R4.3 XXX °C Room air temperature setpoint for comparison
Hystersis R4.3 XXX K Room air temperature hysteresis setpoint
