Menu3-3ToggleSetpoints
TOGGLE POS: XXXXX Entry Default
Status XXX Setpoint toggle status (OFF/ON) of alternative
set of setpoints (setpoint toggle)
Toggle Setp. XXX Setpoint toggle via
EXT digital input D21/22
INT internal timer
CANbus-„--"deactivated
Note: Care should be taken that the
corresponding digital input D21/D22 is set to
SOLLW.UMSCH (menu 6-2-4)
, ,(EXT,INT,CAN,--)
EXT
Alt ON: DD-DD hh:mm Start time for toggle to alternative set of
setpoints
Weekday from - to XXXXX, time hh:mm
Only shown when internal setpoint toggle is
activated (Menu 3-3)
, ,(Mo-Suetc.)ornumbers
(hh:mm)
Mo-Su
21:00
AltOFF: DD-DD hh:mm End time for toggle to alternative set of
setpoints
Weekday from - to XXXXX, time hh:mm
Only shown when internal setpoint toggle is
activated (Menu 3-3
, ,(Mo-Suetc.)ornumbers
(hh:mm)
Mo-Su
05:00
Alt ON: DD-DD hh:mm Start time for toggle to alternative set of
setpoints
Weekday from - to XXXXX, time hh:mm
Only shown when internal setpoint toggle is
activated (Menu 3-3)
, ,(Mo-Suetc.)ornumbers
(hh:mm)
Su
05:00
AltOFF: DD-DD hh:mm End time for toggle to alternative set of
setpoints
Weekday from - to XXXXX, time hh:mm
Only shown when internal setpoint toggle is
activated (Menu 3-3
, ,(Mo-Suetc.)ornumbers
(hh:mm)
Su
21:00
... A total of 7 different ON and OFF toggle times
can be defined. A toggle time will only be
obeyed when a matched pair of on and off
times is set as a parameter.
