The following controller types can be set using the DIP switch S3:
Controller type or master / slave mode DIP switch S3 (switch positions of the coding switches 1 .. 9)
1 2 3
4
Master /
Slave mode
5 6 7 8
9
Nor
mal
Ope
rati
on /
Fir
mw
are
Upd
ate
(onl
y
2nd
gen
erat
ion
con
troll
ers)
Case controller UA 111 OFF OFF OFF ON/OFF OFF OFF OFF OFF
ON
UA 111 D OFF ON ON ON/OFF OFF OFF OFF OFF
ON
UA 121 ON OFF OFF ON/OFF OFF OFF OFF OFF
ON
UA 131 without
fan control
UA 131 with fan
control
(terminals 73/74)
OFF ON OFF ON/OFF OFF
ON
OFF OFF OFF
ON
UA 131 LS with
enhanced fan
control
(terminals
15/16/18)
ON ON ON ON/OFF ON OFF OFF OFF
ON
UA 131 DD ON ON ON OFF OFF OFF OFF OFF
ON
UA 141 ON ON OFF ON/OFF OFF OFF OFF OFF
ON
Cold room controller UR 141 NK OFF OFF ON ON/OFF OFF OFF OFF OFF
ON
UR 141 TK ON OFF ON ON/OFF OFF OFF OFF OFF
ON
* Enable of special functions. Information about whether the DIP switch 8 must be set to ON can be found for
the corresponding functions in the chapter Function of UA 400 / UA 410. After the DIP switch 8 has been
changed, a controller restart must always be performed, otherwise the setting will not be adopted.
Due to the setting of the controller type, only a part of the functions and parameters of the case controller is
alwaysavailable.
In the case of any setting of coding switch combinations that are not present in the list, UA 131 is automatically
appliedascontrollertypeandanalarmmessageiscreated.
