Operation of VS 300
96
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
7.16.2.1 System Centre CI 4x00
The terminal for remote control of the controller (Menu 2-2 or Menu 4-2) is called in the system centre as fol
lows:
Step 1: Tap "2 - System overview" or "4 - Configuration" in the main menu.
If "2" is selected, the values below are only displayed as read-only,
for "4", lock-down must previously be removed by logging in (see chapter 7.3.3) so that
settings below can be made.
Step 2: Tap "2 Case controllers" and select the required controller in the list that is then displayed
using the cursor buttons (↑) and (↓). In the screen that opens, the
name, position designation and the alarm priority of the controller can be input as required.
Step 3: The main menu of the controller is then displayed by tapping the "Remote control" button:
7.16.2.2 Store computer CI 3x00 / operator terminal AL 300
The main menu of the controller is called in the store computer or operator terminal as follows:
Step 1: Select the submenu "5 Remote control" in the main menu (see graphic).
Main menu
4 Messages ↑
5 Remote control
6 Store computer ↓
Step 2: Select the required controller using the cursor buttons (↑) und (↓) or
by input of the CAN bus address (node number nnn) using the digit buttons.
Thereby, the following screen is displayed:
REMOTE CONTROL Kn.nnn
Node Name ↑
Item ID XXXXX↓
Step 3: The main menu of the controller is then displayed in the terminal by tapping the ENTER button
KÜHLSTELLE Pos: XXXXX
1 Istwerte ↑
2 Sollwerte
3 Uhr ↓
4 Meldungen
5 Archiv
6 Konfiguration ↓
To Next Page
