8 Parameter List and Menu Structure of VS 300
The integral user interface or an external terminal (CI 3000 Store Computer and AL 300 Operator Terminal) can
be used for configuring, parameter setting and operation of the VS 300 Pack Controller by means of menus and
screens. The following sections describe the parameter list of the VS 300 and the menu structure of the external
in detail.
The following abbreviations are used in the parameter lists and menu structure:
Dim. Dimension/SI unit CL# Control Loop 1/Control Loop 2
I1..I4 Input 1 to 4 CL1 Control Loop 1
FC Frequency changer CL2 Control Loop 2
HP High pressure SP Setpoint
AV Actual value D Day operation
N Night operation LT Low-temperature refrigeration
LP Low pressure + High temperature/pressure, above neutral zone
NT Normal-temperature refrigeration - Low temperature/pressure, below neutral zone
Prio Priority = Temperature/pressure, within neutral zone
(2) Shown only when CL is configured as HP controller
8.1 Parameter list
The parameter list of the VS 300 is divided into separate groups:
A (A000..A060) Actual Values System data
S1 (S100..S113) Setpoints 1 Basic Controller Parameters
S2 (S200..S290) Setpoints 2 Auxiliary Controller Parameters
S3 (S300..S394) Setpoints 3 System Configuration
S4 (S400..S432) Setpoints 4 Alarm Priorities
S5 (S400..S554) Setpoints 5 Suction pressure shift / Additional parameters
t (t000..t027) Timer Setpoints Timers
C (C000..C040) Check-Modus Service Mode (outputs can be actuated manually)
F (F001..F100) Fault Reports Process and System Fault Reports
Setpoints can only be changed at access level 1 (setpoint adjustment enabled) or 10 (Superuser
mode) - (see section 7.7 Changing the Access Level)! Unless stated otherwise, parameters are al
ways configured at setpoint adjustment enabled access level in the following descriptions. The
LED display flashes to indicate when values (setpoints) can be changed.
Faulty parameter setting can cause serious impairment of function.
