Alarms and Messages of VS 300
157
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
10.6 System fault reports
RAM error is a fatal error and causes the VS 300 Pack Controller to go into fault status, as correct running of the
program is then no longer likely. The watchdog attempts to reset the controller and force a restart. The controller
will not start if the RAM error is permanent.
Message/alarm No.
LED display VS 300
Display text
AL 300 or CI 3000
System fault report
E000 Internal error Internal error
E004 EEPROM error EEPROM parameter memory defective - not responding
E005 EEPROM checks. Faulty EEPROM content (checksum)
E008 RTC error Internal clock defective
E009 I/O module error Internal bus system fault
E010 Battery voltage Internal battery low
E050 First start First start with default parameters
E051 Power failure Restart following power failure
10.7 Process fault reports
Message/alarm No.
LED Display VS 300
Display text
AL 300 or CI 3000
System fault report
E180 Service mode Service mode active
E181 Fast return CL1/2 Fast unload active in Control Loop 1 or 2
E182 Load shed CL1/2 Load shedding active in Control Loop 1 or 2
E203 Sens.type change Pressure sensor parameter changed
E207 Press.too high HP1 High pressure in Control Loop 1; (LT1, NT1 or HP1)
E208 Press.too high HP2 High pressure in Control Loop 2; (LT2, NT2 or HP2)
E209 Press.too low CL1 Low pressure in Control Loop 1 (LT1, NT1 oder HP1)
E210 Press.too low CL2 Low pressure in Control Loop 2 (LT2, NT2 oder HP2)
E211 Meas.err. CL1 Pressure sensor measuring loop Control Loop 1
E212 Meas.err. CL2 Pressure sensor measuring loop Control Loop 2
E222 No Load Level CL1 No Load Level in Control loop 1
E223 No Load Level CL2 No Load Level in Control loop 2
E224 No UA 300 No UA 300 found with refrigeration point control
E240 Setpoint changed Setpoint changed
E241 config. changed Controller configuration changed: LTLT, LTNT, LTHP, NTNT, NTHP, HPHP, NTLT
E243 Ext. Message E1 Digital alarm input 1 active
E244 Ext. Message E2 Digital alarm input 2 active
E245 Ext. Message E3 Digital alarm input 3 active
E246 Ext. Message E4 Digital alarm input 4 active
