Parameter List and Menu Structure of VS 300
112
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
8.1.15 Parameter List C: Service / Check Mode - Defaults Relay Outputs
Parameter
No.
Function
Description
Range Default Dim. Displayed / Condition
C010
nr 01
..
nr [m]
CL1
Default actuating sta
tus of relay/control
stages
0: Output not
actuated
1: Output
actuated
0 - Minimum of one stage must be defined in CL1:
S301 > 0
[m] = Basic configuration (<=4): [Value S301]
1st expansion stage (<=8): [Value S301]
2nd expansion stage (<=12): [Value S301]
C020
nr [n]
..
nr [o]
CL2
Default actuating sta
tus of relay/control
stages
0 - Minimum of one stage must be defined in CL2:
S331 > 0
[n] = [Value S301] + 1
[o] = Basic configuration (<=4): [n][Value S331]
1st expansion stage (<=8): [n][Value S331]
2nd expansion stage (<=12): [n][Value S331]
C030
nr [p]
..
nr [q]
Default actuating sta
tus of internal alarm
relay / alarm control
stages
0 - Only visible when at least 1 stage is parameterised as
an alarm relay: S376 >0:
S376 = 1
[p] = not applicable
[q] = Basic configuration: 4
1st expansion stage: 8
2nd expansion stage: 12
S376 = 2
[p] = Basic configuration: 3
1st expansion stage: 7
2nd expansion stage: 11
[q] = Basic configuration: 4
1st expansion stage: 8
2nd expansion stage: 12
C040
nr 01
..
nr 02
Alarm card
Default actuating sta
tus of alarm relays
0 - Always shown
(Outputs can however only be actuated when
VS 300 is fitted with optional alarm relay module.)
Number of relay stages CL1 [ValueS301] + Number of relays CL2 [Values S331] + number internal
alarm relay <= Number of relays stages VS 300 (varying with expansion stage/number of relay
stages can be 4/8/12)
Parameter List C: To change values set access level to setpoint adjustment enabled
(Parameter A060=1, see section 7.7 Changing the Access Level).
