Parameter List and Menu Structure of VS 300
105
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
8.1.7 Parameter List S2: Common Setpoints
Parameter
No.
Function/
Description
Range Dim. Displayed / Condition
S280 Current time, hour 0..23 Hour
Always shown
S281 Current time, minute 0..59 Minutes
S282 Current date, day 1..31 Day
S283 Current date, month 1..12 Month
S284 Current date, year 1900..2155 Year
S285 Adjustment for daylight
saving time changes
0:
Not adjusted
1:
Adjusted
-
S290 CAN bus adress ---, 101..109 -
Date and time only need to be set, and only can be set, in stand-alone operation! When the VS 300 is
connected via CAN bus module to a master clock (CI 3000 Store Computer or AL 300 Operator Termi
nal), the date and time will be supplied by this master and applied to the VS 300, meaning that they
then cannot be changed.
Parameter List S2: To change values set access level to setpoint adjustment enabled
(Parameter A060=1, see section 7.7 Changing the Access Level).
8.1.8 Parameter List S3: Setpoints System Configuration
CL1 CL2 Function/
Description
Range Default Dim.
Displayed / Condition
(1): Minimum of one stage must
be defined in CL:
CL1: S301 > 0
CL2: S331 > 0
NT LT HP
S300 S330 Control type 0: Step control
1: Speed control
2: Combined control
0 0 0 - (1) and only available in con
junction if CL is configured as
HP controller
S301 S331 Number of base load
stages
S300/330=0: 0 - max
1)
S300/330=1: 1 or 2
S300/330=2: min 2 - max
1)
2/4/8
2)
-
Always shown
S302 S332 Number of capacity
stages each base
load stage
S300/330=0: 1 - 3
1)
S300/330=1: = 1
S300/330=2: = 1
1 1 1 -
(1)
Only available in conjunction
with step control!
S303 S333 Number of capacity-
controlled base load
stages
S300/330=0: 0..
[Value S301/331]
1)
S300/330=1: = 0
S300/330=2: = 0
0 0 0 -
