ECKELMANN VS 300 - New Features Compared to Earlier Versions

System Design of VS 300
9
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
2.1 New features compared to earlier versions
From Version 2.10:
S Increase of the system stability
From Version 2.09:
S Following refrigerants are supported:
R22, R502, R134a, R404A, R402A, R717, R1270, R507, R407C, R410A, R290, R744 (transcritical operation
not available), R407F, R422A, R422D, R408A, R407D, R407A, R427A, R438A, R512a, R170, R600, R600a,
R449A, R450A, R448A, R455A, R447B, R1234ze, R1233zd, R41234yf
From Version 1.74:
S Extended range for pressure transmitter (up to 75 bar)
From Version 1.72:
S Centralized time synchronization (master clock):
Date and time can be set with the pack controller for the complete system, if no System Centre, Store Com
puter or Operating Terminal ar available. Also performs cyclic synchronization of internal clocks in all E*LDS
components via the CAN bus.
From Version 1.55:
S Demand dependent t
0
-shift
S Monitoring of the minimum t
0
-t
c
difference
As of November 01, 2006, the pack controller is produced in a new unit version!
A point to note in wiring is that arrangement of the connections for digital and analog inputs has
been modified as part of advanced technical design (see illustration):
ADDRESS
CAN-BUS
DIGITAL 230 V AC
1
4
2
3
1
A41
A42
A51
A52
1
2
3
4
D31
D32
D41
D42
D12
D11
D21
D22
A12
A22
A32
A21
A11
A31
5
0
2
3
1
4
6
7
8
9
TTY
ANALOG IN | ANALOG OUT
ADDRESS
TTY ANALOG OUT
INPUTS
DIGITAL 230 V AC
ANALOG
1
A41
A42
A51
A52
1
2
3
4
D31
D32
D41
D42
D12
D11
D21
D22
A12
A22
A32
A21
A11
A31
CAN-BUS
4
2
3
1
5
0
2
3
1
4
6
7
8
9
NEW
ARRANGEMENT
UNTIL
NOW
ZNR. 51203
63 830 E0
From Version 1.46:
S NTLT controller configuration introduced
S Consumer control with compressor speed control
S Support for English and French languages
