ECKELMANN VS 300 - Menu 0 Main Menu

Parameter List and Menu Structure of VS 300
120
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
8.4.1 Menu 0 Main menu
VS 300 POS: XXXXX
1 Summary Next: Menu 1
2 Actual Values Next: Menu 2
3 Setpoints Next: Menu 3
4 Clock Next: Menu 4
5 Messages Next: Menu 5
6 Operating Data Next: Menu 6
7 Default settings Next: Menu 7
8 Service Mode Next: Menu 8
8.4.2 Menu 1 Summary
Act.tx CL1 +/-/= XXX °C CL1: Actual value of evaporating/condensing temperature
Setp.tx CL1 D/N/HR XXX °C CL1: Calculated setpoint of evaporating/condensing temperature
Act.tx CL2 +/-/= XXX °C CL2: Actual value of evaporating/condensing temperature
Setp.tx CL2 D/N/HR XXX °C CL2: Calculated setpoint of evaporating/condensing temperature
D Day operation
N Night operation
tx t
0
or t
c
HR Heat recovery mode
+ Temperature high, above neutral zone
- Temperature low, below neutral zone
= Temperature within neutral zone
8.4.3 Menu 2 Actual values
ACT.VALUES POS: XXXXX
1 Analog values Next: Menu 2-1
2 Compressor/Cond.Fan CL1 Next: Menu 2-2
3 Compressor/Cond.Fan CL2 Next: Menu 2-3
4 INT ALARM Next: Menu 2-4, only shown if parameter No.AlRelays <0, see menu 3-1
5 System Next: Menu 2-5
