ECKELMANN VS 300 - Parameter List T: Setpoints Timers

Parameter List and Menu Structure of VS 300
111
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
8.1.13 Parameter List t: Setpoints Timers
CL1 CL2 Function/
Description
Range
Dimension
Default Displayed / Condition
NT LT HP
t000 t020 Setpoint toggle
internal/external
0: External
1: Internal
- 0 0 0
Minimum of one stage must be
defined in CL:
CL1: S301 > 0
CL2: S331 > 0
t001 t021 Timer 1
Sd 0..10 0: Mon
1: Tue
2: Wed
3: Thu
4: Fri
5: Sat
6: Sun
7: Mon-Sun
8: Mon-Fri
9: Mon-Sat
10: Sat-
Sun
-- -- --
Sh 0..23 Hour
0 0 0
S 0..59 Minute
0 0 0
Ed 0..10 0: Mon
1: Tue
2: Wed
3: Thu
4: Fri
5: Sat
6: Sun
7: Mon-Sun
8: Mon-Fri
9: Mon-Sat
10: Sat-
Sun
-- -- --
Eh 0..23 Hour
0 0 0
E 0..59 Minute
0 0 0
t002 t022 Timer 2
As above As above As above
t003 t033 Timer 3
t004 t024 Timer 4
t005 t055 Timer 5
t006 t026 Timer 6
t007 t027 Timer 7
Parameter List t: To change values set access level to setpoint adjustment enabled
(Parameter A060=1, see section 7.7 Changing the Access Level).
8.1.14 Parameter List C: Service / Check Mode - Defaults Analog Outputs
Parameter
No.
Function
Description
Range Default Dim. Displayed
C000 CL1
Controller output de
fault
Analog output
0..10,0 0,0 V Always shown
C001 CL2
Controller output de
fault
Analog output
0..10,0 0,0 V
