ECKELMANN VS 300 - 8.3 Menu Structure Overview

Parameter List and Menu Structure of VS 300
108
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
8.1.10 Parameter List S3: Basic Settings System Configuration
Parameter
No.
Function /
Description
Range Default
Dim. Displayed /
Condition
NT LT HP
S390 Select controller confi
guration
0: CL1 = LT control
CL2 = LT control
- - - -
Requires Superuser mode ac
cess rights
(Parameter A060 = 10)
1: CL1 = LT control
CL2 = NT control
2: CL1 = LT control
CL2 = HP control
3: CL1 = NT control
CL2 = NT control
4: CL1 = NT control
CL2 = HP control
5: CL1 = HP control
CL2 = HP control
6: CL1 = NT control
CL2 = LT control
S391 Load default settings 0: Preserve existing settings
1: Load default settings
0 0 0 -
S392 Parameter backup 0: No parameter backup
1: Back up parameters
0 0 0 -
S393 Delete run time archi
ves
0: Preserve archives
1: Delete archives
0 0 0 -
S394.1[1]..
S394.[m]
und
S394.[n]..
S394.[o]
Reset operating hours
for relay stages 1 - 12
1)
0: Preserve operating hours
1: Reset operating hours to 0
- - - -
Requires Superuser mode ac
cess rights
(Parameter A060 = 10)
CL1: S301 > 0
[m]=
Basic configuration (<=4):
[Value S301]
1st expansion stage (<=8):
[Value S301]
2nd expansion stage (<=12):
[Value S301]
or
CL1: S331 > 0
[n]= Value S301] + 1
[0]=
Basic configuration (<=4):
[n] + [Value S331]
1st expansion stage (<=8):
[n] + [Value S331]
2nd expansion stage (<=12):
[n] + [Value S331]
1)
Maximum values varying with expansion stage/Number of relay stages can be 4/8/12
