ECKELMANN VS 300 - Menu 4 Clock

Parameter List and Menu Structure of VS 300
138
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
8.4.5 Menu 4 Clock
CLOCK POS: XXXXX Entry
Default
NT LT HP Dim.
Current time → Show current date/time Screen 4-a
Setp.toggle CL1 XXX Setpoint toggle external or by internal
clock CL1
↑, ↓
(EXT, INT)
EXT EXT EXT -
Toggle time CL1 → Toggle times CL1;
shown only with toggle by internal clock
Screen 4-b
Setp.toggle CL2 XXX Setpoint toggle external or by internal
clock CL2
↑, ↓
(EXT, INT)
EXT EXT EXT -
Toggle time CL2 → Toggle times CL2;
shown only with toggle by internal clock
Screen 4-c
S Screen 4-a Current Time
CLOCK POS: XXXXX Entry
Date: XX TT.MM.JJ XX = current weekday, DD = day, MM: month, YY = year -
Time: Current time -
Auto dayl. savg X Adjust for automatic daylight saving changes -
Date, time and adjustment for daylight saving change cannot be changed in this screen! Changes
can only be made in main menu of operating terminal (Menu 9 Parameter Setting - 1 Date/Time).
S Screen 4-b Setpoint Toggle CL1
TOGGLE POS: XXXXX Entry
dd hh:mm dd hh:mm
Enter up to 7 start/end times for 2nd setpoint ON in CL1
Start/End
dd: Mon, Tue, Wed, Thu, Fri, Sat, Sun, Mon-Sun
hh: Hour
mm: Minute
↑, ↓, ↵
...
dd hh:mm dd hh:mm
S Screen 4-c Setpoint Toggle CL2
TOGGLE POS: XXXXX Entry
dd hh:mm dd hh:mm
Enter up to 7 start/end times for 2nd setpoint ON in CL2
Start/End
dd: Mon, Tue, Wed, Thu, Fri, Sat, Sun, Mon-Sun
hh: Hour
mm: Minute
↑, ↓, ↵
...
dd hh:mm dd hh:mm
