Parameter List and Menu Structure of VS 300
137
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
S Menu 3-6 Alarms
MELDUNG POS: XXXXX Entry
Default
NT LT HP Dim.
px high CL1 X High pressure CL1
1)
-, 0, 1, 2
2)
2 2 2 -
px high CL2 X High pressure CL2
1)
2 2 2 -
px low CL1 X Low pressure CL1 2 2 2 -
px low CL2 X Low pressure CL2 2 2 2 -
Meas.err. px CL1 X Pressure measuring loop error CL1 2 2 2 -
Meas.err. px CL2 X Pressure measuring loop error CL2 2 2 2 -
Service Mode X Service mode activated 0 0 0 -
Load shed X Load shedding activated 0 0 0 -
Fast return X Fast unload activated 0 0 0 -
Setpoint changed X Setpoint changed 0 0 0 -
Config. changed X Controller configuration changed: LT, NT,
HP
0 0 0 -
Ext. Messages E1 X External alarm through digital input 1 2 2 2 -
Ext. Messages E2 X External alarm through digital input 2 2 2 2 -
Ext. Messages E3 X External alarm through digital input 3 2 2 2 -
Ext. Messages E4 X External alarm through digital input 4 2 2 2 -
Senstype change X Sensor type changed 2 2 2 -
Power failure X Power failure/restart 1 1 1 -
First start X First start 2 2 2 -
Battery voltage X Battery low 2 2 2 -
Int.Error X Internal error 2 2 2 -
No UA300 X No UA 300 found with refrigeration point
control
2 2 - -
1)
Only shown when CL is configured as HP controller.
2)
- Not recorded 0 Only entered in report list
1 Alarm priority 1 2 Alarm priority 2
S Menu 3-7 Parameter Backup
VS 300 POS: XXXXX Entry
Save Parameters?
Back up parameters: The VS 300 allows of saving a backup set of data
that will be loaded instead of the default settings in occurrence of an inter
nal error (inconsistency in parameter memory).
ESC, ↵
Are you sure ?
No: ESC Yes: ↵
Parameter backup should be carried out following individual and successful parameter setting and
system startup.
