Parameter List and Menu Structure of VS 300
101
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
3)
Values of more than 4 digits (e.g. 21900 operating hours) are displayed with the help of the relay stage
operating and status indicators (LED flashing) as follows:
Value = Value of LED display [0 - 9999] + (Number of flashing operating and status indicator LED * 10000)
4)
Status of digital inputs I1 - I4 is shown on the 4-digit LED display as follows, from left to right:
1st digit = Input 1 2nd digit = Input 2
3rd digit = Input 3 4th digit = Input 4
5)
Status of alarm outputs A1 - A2 is shown on the 4-digit LED display as follows, from left to right:
1st digit = 0 2nd digit = 0
3rd digit = Alarm output 1 4th digit = Alarm output 2
Parameter List A: Entries cannot be made (actual values)! Exception: Parameter A060 only (used
to enable access level)!
8.1.3 Parameter List S1: Overview of Main Setpoints - Day/Night Operation
CL1 CL2 Function/
Description
Range Default Dim. Displayed / Condition
NT LT HP
S100 S110 First setpoint t
max
-50..45 -12 -38 25 °C (1)
S101 S111 First setpoint t
min
-50..35 -16 -40 25 °C (1), and temperature shift must be activated in CL:
CL1: S310 = 1 / CL2: S340 = 1
S102 S112 Second setpoint t
max
-50..45 -10 -38 25 °C (1)
S103 S113 First setpoint t
min
-50..35 -14 -36 25 °C (1), and humidity shift must be activated in CL:
CL1: S310 = 1 / CL2: S340 = 1
8.1.4 Parameter List S2: Setpoints Basic Parameters - Day Operation
CL1 CL2 Function/
Description
Range Default Dim. Displayed / Condition
NT LT HP
S200 S240 First setpoint t
max
-50..45 -12 -38 25 °C Minimum of stage must be defined in CL:
CL1: S301 > 0 / CL2: S331 > 0
S201 S241 First setpoint t
min
-50..35 -16 -40 25
°C
(1), and temperature shift must be activated in CL:
CL1: S310 = 1 / CL2: S340 = 1
S202 S242 first setpoint
t-adjust.
_max
16..45 25 25 30
°C
S203 S243 first setpoint
t-adjust.
_min
0..20 15 15 0
°C
S204 S244 Neutral zone 1st SP 1..10 4 4 6
K
Minimum of stage must be defined in CL:
CL1: S301 > 0 / CL2: S331 > 0
S205 S245 Control constant 1st SP 1..10 10 7 10
S206 S246 Activate humidity shift 0: nicht
aktiv
1: aktiv
0 0 0
-
(1), and humidity shift must be activated in CL:
CL1: S311 = 1 / CL2: S341 = 1
