ECKELMANN VS 300 - Parameter List F: Alarms - System and Process Fault Reports

Parameter List and Menu Structure of VS 300
113
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
8.1.16 Parameter List F: Alarms - System and Process Fault Reports
The status LEDs of the relay/control stages indicate the currently displayed alarm detail (see illustration: day
(15th) of receive time stamp is displayed):
Parameter
No.
Function
Description
Range Dimension Displayed
F001.1
...
F001.12
Most recent alarm:
Only shown when alarms are still active (indica
ted by flashing)
or
when alarms have not been cancelled by ESC/
RESET.
.1: Message/alarm code E001..E246
.2: Message/alarm status 0: Alarm not
active
1: Alarm active,
alarm still current
-
.3: Receive time stamp: day 1..31 Day
.4: Receive time stamp: month 1..12 Month
Only shown when alarms are still active (indica
ted by flashing)
or
when alarms have not been cancelled by ESC/
RESET.
.5: Receive time stamp: year 1900..2155 Year
.6: Receive time stamp: hour 0..23 Hour
.7: Receive time stamp: minute 0..59 Minute
.8: Send time stamp: day 1..31 Day
.9: Send time stamp: month 1..12 Month
.10:Send time stamp: year 1900..2155 Year
.11:Send time stamp: hour 0..23 Hour
.12:Send time stamp: minute 0..59 Minute
F002.1
..
F002.12
2nd most recent alarm:
As above
As above
Fnnn.1
..
Fnnn.12
Oldest alarm:
As above
Values of Fnnn: F001 - F100 (maximum number of alarms 99)
Parameter List F: Access level does not require enabling!
By contrast with alarms that are no longer current (have been cancelled), current alarms are shown
flashing. Alarms can be cancelled by pressing the ESC/RESET key.
