ECKELMANN VS 300 - Page 122

Parameter List and Menu Structure of VS 300
114
Doku-Version 2.05 - Firmware 2.10 - 15. September 2017
Identification of displayed value by relay-control stage status LEDs
ZNR. 51203 51 230
E0
ESC
RESET
1 2 3 4
1 2
5 6 8
9 10 11 12
7
Status
12
OFF
//
OFF
1
2
3
4
5 6
7
8
9
10 11 12
( 1) Message/alarm code:
(2)Message/alarm status:
(3)Receive time stamp:
( 4) Receive time stamp:
(5)Receive time stamp:
( 6) Receive time stamp:
( 7) Receive time stamp:
( 8) Send time stamp:
( 9) Send time stamp:
(10) Send time stamp:
(11) Send time stamp:
(12) Send time stamp:
E001..E246
0: not active / 1: active
Day
Month
Year
Hour
Minute
Day
Month
Year
Hour
Minute
Items 8 to 12 are not displayed when alarm status is 1 (alarm active)!
