8.4.6 Menu 5 Alarms
MESSAGE POS: XXXXX
1 Display Next: Screen 5-1
2 Delete Next: Screen 5-2
S Menu 5-1 Show
MESSAGE POS: XXXXX Entry
XXXXXXXXXXXXXXXXXXXXXXXXXXXX
dd.mm.yy hh:mm EIN/AUS
Show alarm text with date and time
ON/OFF: Alarm active / Alarm no longer active
↑, ↓
S Menu 5-2 Delete
MESSAGE POS: XXXXX Entry
Delete !
Are you sure ?
No: ESC Yes: ↵
Safety prompt for deleting alarms ESC, ↵
8.4.7 Menu 6 Operating Data
OP DATA POS: XXXXX
1 On time CL1 Next: Screen 6-1
2 On time CL2 Next: Screen 6-2
3 History CL1 Next: Screen 6-3
4 History CL2 Next: Screen 6-4
5 Clear Archive Next: Screen 6-5
S Screen 6-1 Run Times CL1
OP DATA POS: XXXXX Entry
On time S 1 XXXXX h Show operating hours for compressor/fan stage 1
1)
↵, number
...
On time S 12 XXXXX h Show operating hours for compressor/fan stage 12
1)
↵, number
1)
Number of relay/control stages CL1 [1..n] + Number of relays CL2 [n+1..m] + Number internal alarm relais
<= Number of relay/control stages VS 300 (max. 4, 8, 12 depending on expansion stage and configuration);
see section 4.1.1 System Configuration - Allocation of Relay/Control Stages
